Ultra Charger (48amps)
1. $599 deposit required. Refunded after 1,500 kWh of charging
2. $30 shipping fee
3. 48amps (60amps breaker), 18 feet charging cable
4. Roulez Vert & BC Hydro rebate eligible
5. Earn 11¢ per kWh charged
6. Lifetime warranty
Use Discount Code provided by DashSharing Channel Partners for discounted deposit amount at checkout.
*Once you reach 1,500 kWh, you’ll receive a full refund of the final deposit amount you paid while checking out.
Product Specifications
Product Specification
General Features
General Features
- Charging mode: Level 2
- Vehicle connection: SAE J1772 or NACS1 plug with 18' cable
- AC power output: 7.4kW/32A, 9.6kW/40A, 11.5kW/48A
- Mounting options: Wall and post mounting
- Digital Screen: 2.8" LCD Screen
- Charging status LED: Yes
- Load management: via OCPP platform
Communication, Certificates and Standards
Communication
- Interfaces: Ethernet, WiFi, Bluetooth
- User authentication: App
- Back-end protocol: OCPP 1.6J
- Software upgrade: Over the air (OTA)
Certificates and Standards
- ETL listed: UL2594, CSA C22.2#280
General Design and Electrical Details
General Design
- Environmental rating: NEMA 3R
- Dimensions (HxWxD): 325.3 x 230.6 x 143 mm
- Weight: 6.6 kg
- Ambient conditions: Operating temperature -30°C to +50°C, 5% to 95% RH
- Shell material: PC + Glass
- Colours: Grey, PC
Electrical Details
- Power supply voltage: Single phase, 208V/240V AC, 60 Hz
- Rated current settings: 32A, 40A, 48A
- Power wiring: 3 Wire, L1, L2 plus ground
- Earth leakage protection & ground fault protection: Yes
- Overvoltage/undervoltage protection: Yes
- Over current protection: Yes
- Operating altitude: ≤ 2000m
Want help with installation?
We offer charger swap as well as new inatallation in GTA
Only used it once so far, but it was easy to setup and seems to work very well. Also it's a fairly nice looking package imo.
Very good. Simple
love how it tracks everything and has been working great!
So far so good, getting it set up was very straight forward, I'm already progressing nicely towards the initial deposit refund. Looking forward to seeing how things play out.
Nice dashboard and easy to follow.
Charger was a clean easy instal, setting up the app easy. I wish the charger cable was longer so reach my car in its parking spot easier. I couldn’t install the unit outside due to restrictions. If the cable was a few feet longer it would have reached very easily.
Arrived in 3 buss days. Easy install and works great!
The charger and app are so easier to set up. Took me 10mins from unboxing to be able to charge my car! Would recommend for sure.
Arrived very quickly.
